UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable

Alle Produkte
Industrielles Flachkabel (216)
Einkerniges Flachkabel (25)
Mehradriges Flachkabel (27)
Haken herauf Draht (54)
Aufladungskabel EV (52)
Kabel des medizinischen Geräts (19)
Schreiben Sie TC-ER Kabel (10)
Automobilkabel-Draht (15)
Gewundene Stromkabel (14)
Signalübertragungs-Kabel (19)
Koaxialstromkabel (12)
Widerstand-Ankerkette (13)
Computer-Verbindungs-Kabel (11)
Einzelnes Leiter-Kabel (36)
multi Leiterkabel (38)
Servobewegungskabel (10)
Energie-Kabel (16)
Elektrisches Flachkabel (10)
Beste Produkte
Awm20549 2p 22AWG 300V SR-PVC-PVC-HDPE 80 Grad Celsius

Awm20549 2p 22AWG 300V SR-PVC-PVC-HDPE 80 Grad Celsius

UL2464 13Cx26AWG (7/0.16T) + Grad 300V EA 80

UL2464 13Cx26AWG (7/0.16T) + Grad 300V EA 80

XLPE-Isolierung UL21408 300V FT2

XLPE-Isolierung UL21408 300V FT2

Bescheinigung
China NANTONG HWATEK WIRES AND CABLE CO.,LTD. zertifizierungen
China NANTONG HWATEK WIRES AND CABLE CO.,LTD. zertifizierungen
vielen Dank für Ihre schnelle Antwort. Ihre Berufskabellösung hilft mir heraus, Kabelqualität ist sehr gut. Sie passt unsere Verbindungsstücke

—— Gonalze

Ihre Produktqualität über meinem hinaus stellen sich vor, schätze ich in hohem Grade Ihre große Unterstützung, haben Hoffnung die bessere und tiefere Zusammenarbeit in der Zukunft.

—— Bharath

Ich bin online Chat Jetzt

UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable

UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable

Großes Bild :  UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable

Produktdetails:
Herkunftsort: CHINA
Markenname: HWATEK
Zertifizierung: UL
Modellnummer: CL2
Zahlung und Versand AGB:
Min Bestellmenge: 1000
Preis: negotiable
Verpackung Informationen: Rollen oder Rollen
Lieferzeit: 4 Wochen
Zahlungsbedingungen: T/t
Versorgungsmaterial-Fähigkeit: 1000 km/ Monat
Kontakt
Ausführliche Produkt-Beschreibung
Nennspannung: 150 V Nenntemperatur: 75ºC
Leitermaterial: Bloßes kupfernes angeschwemmt Leitergröße: 16/0,254 mm
Isolationsmaterial: SR-PVC Isolationsdicke: 0,23 mm
Min -Isolationsdicke: 0,2 mm Außendurchmesser: 10,70 ± 0,10 mm
Mantelmaterial: PVC Jacke Dicke: 0.84mm
Min Jacke Dicke: 0.66mm Kabel Außendurchmesser: 7,6 ± 0,30 mm
Max DC -Widerstand: 21,4 Ω/km Zugfestigkeit: ≥ 10,3mpa
Verlängerung: ≥100% Spezifikation: HT2504809

UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable 0
Product Specifications
Construction
Conductor Bare copper starned
Cross section 18AWG
Construction 16/0.254mm
Strand Dia. 1.18mm
Insulation SR-PVC
Nom.Thickness 0.23mm
Min.Thickness 0.20mm
Insulation Dia. 1.70±0.10mm
Insulation colour 1.white 2.red 3.green 4.blue 5.yellow 6.brown 7.orange 8.black
Filler optional
Assembly 8Cx18AWG
Jacket PVC
Nom.Thickness 0.84mm
Min.Thickness 0.66mm
Outer Dia. 7.6±0.30mm
Colour Per request



Conductor Bared copper stranded
Cross section 18AWG
Construction 16/0.254mm
Elongation ≥100%
Aged condition 16/0.254mm
Insulation SR-PVC
Nom.Thickness 0.23 mm
Min.Thickness 0.2 mm
Insulation Dia.1.70±0.10mm

Insulation: :1.white 2.red 3.green 4.blue 5.yellow 6.brown 7.orange 8.black

Jacket: PVC
Reference standard:UL
Nom.Thickness 0.84 mm
Outer Dia. 0.66mm
Colour per request
Performance Characteristics

Electric Performance
Rated Temperature 75℃
Voltage rating 150V
Max.conductor DC resistance(20℃) 21.4Ω/km
Dielectric Strength AC 2.0kV/1min

UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable 1
Company Profile
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable 2
Founded in 2004 with 16 years of development, we Hwatek established our new plant Nantong Hwatek Wires & Cable Co., Ltd in 2020. Located in Nantong City, Jiangsu Province, our new plant covers 34,000 square meters with 100 million investment.
We are dedicating to R&D and produce various wires and cables like industrial control, communication instruments, medical control, green energy EV and special wires and cables etc. OEM & ODM is also available.
Our Capabilities
  • Produce cables with following insulation & jacket: PVC, SR-PVC, XL-PVC(CL PVC), XLPE, FRPE, TPE, FEP etc.
  • Produce cables with temperature range from -40 to 200 degree temperature
  • Produce cables with voltage range from 30V to 1200V DC
  • Flamability rating: VW-1, FT1, FT2
  • 300+ different UL Style approval from UL Authority
  • QMS Certification: ISO9001-2015, IATF16949-2016, ISO13485-2016
  • Product Certification: CCC, UL, CSA, ETL, CE
  • Support drop-in equivalent to any brand of cables and custom made cables
Certifications
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable 3
Production Process
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable 4
Shipping & Logistics
UL13 Power Limited Circuit Cables Type CL2 Bare Copper Stranded Conductor unshield 150 V 75 degree 8 cores 18 AWG cable 5
Frequently Asked Questions
Q: What can you supply?
A: We produce consumer electronics wires, hook up wires, industrial cables, robot cables, EV charging cables, new/green energy cables.
Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
Q: Can we get samples before ordering?
A: Yes, we are willing to arrange samples for you.
Q: What's your lead time?
A: Normally we can finish your orders in 2-3 weeks, and 5-6 weeks in peak season.
Q: How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final inspection before shipment.
